DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
348
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the available entries.
Click the Delete button to remove the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
BGP Extended Community List Settings
This window is used to display and configure the BGP extended community list settings.
To view the following window, click L3 Features > BGP > BGP Extended Community List Settings, as shown
below:
Figure 6-188 BGP Extended Community List Settings Window
The fields that can be configured are described below:
Parameter Description
List Name
Enter the name of the extended community list. This name can be up to 16
characters long. The syntax is general string that does not allow spaces.
Type
Select the type here. Options to choose from are:
• Standard - Specifies to configure a named standard extended community
list.
• Expanded - Specifies to configure a named expanded extended community
list.
Mode
Select the mode here. Options to choose from are:
• Permit - Specifies to permit the extended community list.
• Deny - Specifies to deny the extended community list.
• None - Specifies that no action will be taken.
Extended Community
Select the extended community here. Options to choose from are:
• RT - Specifies to use the Route Target (RT).
• SoO - Specifies to use the Site-of-Origin (SoO).
Enter the extended community string in the space provided.
