DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
590
Figure 13-8 CPU Port Window
The fields that can be configured are described below:
Parameter Description
Type
Select the type of information to display here. Options to choose from are All,
Layer 2 (L2), Layer 3 (L3), and Protocol.
Click the Find button to display entries in the table based on the information selected.
Click the Refresh button to refresh the information displayed in the table.
Click the Clear All button clear all the statistics information displayed in the table.
Interface Counters
This window is used to view the interface counter information.
To view the following window, click Monitoring > Statistics > Interface Counters, as shown below:
