DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
619
The fields that can be configured are described below:
Parameter Description
RCP Server IP
Enter the RCP server IP address here.
User Name
Enter the user name used for the RCP connection here. This name can be up to
32 characters long.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Destination File
Enter the destination path and location where the log file should be stored on the
RCP server. This field can be up to 64 characters long.
Log Type
Select the log type that will be backed up to the RCP server.
• When the System Log option is selected, the system log will be backed up.
• When the Attack Log is selected, the attack log will be backed up.
Click the Backup button to initiate the system log backup.
Ping
Ping is a small program that sends ICMP Echo packets to the IP address you specify. The destination node then
responds to or “echoes” the packets sent from the Switch. This is very useful to verify connectivity between the Switch
and other nodes on the network.
To view the following window, click Tools > Ping, as shown below:
