Parameter Description
appropriate hexadecimal value will automatically be entered.
Ethernet Type Mask
Enter the Ethernet type mask hexadecimal value here. This value must be
between 0x0 and 0xFFFF. When the Ethernet type profile is selected, above, the
appropriate hexadecimal value will automatically be entered.
CoS
Select the CoS value that will be used here. The range is from 0 to 7.
• Mask - Enter the CoS mask value here. The range is from 0x0 to 0x7.
Inner CoS
After selecting the CoS value, select the inner CoS value that will be used here.
The range is from 0 to 7.
• Mask - Enter the inner CoS mask value here. The range is from 0x0 to 0x7.
VID
Enter the VLAN ID that will be associated with this ACL rule here. The range is
from 1 to 4094.
• Mask - Enter the VLAN ID mask value here. The range is from 0x0 to 0xFFF.
Inner VID
Enter the inner VLAN ID that will be associated with this ACL rule here. The range
is from 1 to 4094.
• Mask - Enter the inner VLAN ID mask value here. The range is from 0x0 to
0xFFF.
VLAN Range
Select and enter the VLAN range that will be associated with this ACL rule here.
Enter the starting and ending VLANs in the spaces provided. The range is from 1
to 4094.
Time Range
Enter the name of the time range profile that will be used in this ACL rule here.
This name can be up to 32 characters long.
Click the Apply button to accept the changes made.
Click the Back button to discard the changes made and return to the previous page.
Extended Expert ACL
After selecting an Extended Expert ACL and clicking the Add Rule button, the following page will appear.
