DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
416
Parameter Description
Unit
Select the Switch unit ID that will be used here.
From Port - To Port
Select the Switch port range that will be used here.
Direction
Select the Input direction here. This specifies to apply the policy map for ingress
flow on the interface.
Network QoS Policy Map
Name
Enter the network QoS policy map name here. This name can be up to 32
characters long. Select the None option to not associate this configuration with a
network QoS policy map.
Click the Apply button to accept the changes made.
PFC Port Settings
This window is used to display and configure the Priority-based Flow Control (PFC) port settings.
NOTE: The Priority Flow Control (PFC) feature can only be enabled and used on the 10G ports.
To view the following window, click QoS > QoS PFC > PFC Port Settings, as shown below:
Figure 7-25 PFC Port Settings Window
The fields that can be configured in PFC Port Settings are described below:
Parameter Description
Unit
Select the Switch unit ID that will be used here.
From Port - To Port
Select the Switch port range that will be used here.
Willing
Select to enable or disable the willing feature here. This is used to turn on the
Data Center Bridging Exchange Protocol (DCBX) PFC willing feature which
indicates that the specified local port(s) is/are willing to accept PFC configurations
from a remote system.
Click the Apply button to accept the changes made.
The fields that can be configured in Clear PFC Counters are described below:
