Parameter Description
Trap State
Select to enable or disable port security traps on the Switch.
Click the Apply button to accept the changes made.
The fields that can be configured in Port Security Trap Rate Settings are described below:
Parameter Description
Trap Rate
Enter the number of traps per second. The range is from 0 to 1000. The default value 31 indicates an
SNMP trap to be generated for every security violation.
Click the Apply button to accept the changes made.
The fields that can be configured in Port Security System Settings are described below:
Parameter Description
System
Maximum
Address
Enter the maximum number of secure MAC addresses allowed. If not specified, the default
value is No Limit. The valid range is from 1 to 12288. Tick the No Limit checkbox to allow the
maximum number of secure MAC address.
Click the Apply button to accept the changes made.
The fields that can be configured in Port Security VLAN Settings are described below:
Parameter Description
VID List
Enter the VLAN ID(s) here.
VLAN Max Learning
Address
Enter the maximum number of allowed MAC addresses that can be learned on
the specified VLAN(s) here. The range is from 1 to 12288. Tick the No Limit
checkbox to allow the maximum number of secure MAC address.
Click the Apply button to accept the changes made.
The fields that can be configured in Find VLAN are described below:
Parameter Description
VID
Enter the VLAN ID that will be located here.
Click the Find button to locate a specific entry based on the information entered.
Port Security Port Settings
This window is used to display and configure the port security port settings.
To view the following window, click Security > Port Security > Port Security Port Settings, as shown below:
