DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
401
Click the Apply button to accept the changes made.
Click the Delete button to remove the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Port Trust State and Mutation Binding
This window is used to display and configure the port trust state and mutation binding settings.
To view the following window, click QoS > Advanced Settings > Port Trust State and Mutation Binding, as shown
below:
Figure 7-8 Port Trust State and Mutation Binding Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the range of ports that will be used for this configuration here.
Trust State
Select the port trust state option here. Options to choose from are CoS and
DSCP.
DSCP Mutation Map
Select and enter the DSCP mutation map name used here. This name can be up
to 32 characters long. Select the None option to not allocate a DSCP mutation
map to the port(s).
Click the Apply button to accept the changes made.
DSCP CoS Mapping
This window is used to display and configure the DSCP CoS mapping settings.
To view the following window, click QoS > Advanced Settings > DSCP CoS Mapping, as shown below:
