DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
351
Parameter Description
Layer 2 VPN VPLS address family.
Click the Find button to locate a specific entry based on the information selected/entered.
After clicking the Please Select button, the following page will appear.
Figure 6-191 BGP Summary Table (Please Select) Window
Select the VRF entry and click the OK button to use the selected VRF entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
BGP Routing Table
This window is used to view the BGP routing table.
To view the following window, click L3 Features > BGP > BGP Routing Table, as shown below:
Figure 6-192 BGP Routing Table Window
The fields that can be configured are described below:
Parameter Description
Address Family
Select the address family that will be used here. Options to choose from are:
• IPv4 Unicast - Specifies to display BGP routing information related to the
IPv4 unicast address family.
• IPv4 Multicast - Specifies to display BGP routing information related to the
IPv4 multicast address family.
• IPv6 Unicast - Specifies to display BGP routing information related to the
IPv6 unicast address family.
• VPNv4 All - Specifies to display all BGP routing information related to the
VPNv4 address family.
• VPNv4 RD - Specifies to display BGP routing information related to the
Route Distinguisher (RD) in the VPNv4 address family. Enter the RD in the
space provided.
