Parameter Description
ACL Name
Enter the standard IP access list name that contains the multicast groups to be
mapped. To permit a group, specify ‘any’ in source address field and specify the
group address in destination address field of the access list entry.
Alternatively, click the Please Select button to find and select any of the exiting
access lists configured on this Switch to be used in this configuration.
Click the Apply button to accept the changes made.
Click the Delete button to delete the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
The fields that can be configured in IGMP SSM Mapping Table are described below:
Parameter Description
Group Address
Enter the IGMP multicast group address here.
Click the Find button to locate a specific entry based on the information entered.
After clicking the Please Select button, the following page will appear.
Figure 6-100 IGMP SSM Mapping Settings (Select) Window
Select the ACL and click the OK button to use the selected access list.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
MLD
MLD Interface Settings
This window is used to display and configure the Multicast Listener Discovery (MLD) interface settings.
To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD > MLD Interface Settings,
as shown below:
Figure 6-101 MLD Interface Settings Window
