DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
579
Figure 12-3 VPWS Settings (Show Detail) Window
Click the Back button to return to the previous window.
L2VC Interface Description
This window is used to display and configure the Layer 2 Virtual Circuit (L2VC) interface description.
To view the following window, click MPLS L2VPN > L2VC Interface Description, as shown below:
Figure 12-4 L2VC Interface Description Window
The fields that can be configured for Create L2VC Interface Description are described below:
Parameter Description
L2VC Interface Name
Enter the L2VC interface name here. This name can be up to 64 characters long.
