DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
392
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Edit button, the following page will appear.
Figure 6-242 VRRP Settings (Edit) Window
The fields that can be configured are described below:
Parameter Description
Advertisement Interval
Enter the advertisement interval value here. This is the time interval between
successive VRRP advertisements by the master router. The range is from 1 to
255 seconds. By default, this value is 1 second.
Preemption
Select to enable or disable the preemption feature here. This feature is used to
allow a router to take over the master role if it has a better priority than the current
master.
Priority
Enter the priority value here. The range is from 1 to 254.
BFD Remote IP
Enter the Bidirectional Forwarding Detection (BFD) remote IP address here. This
IP address must be a real IP address of a real device in the same VRRP virtual
group. A BFD session will be created between this VRRP router and its peer.
When the session goes down, if the VRRP is in the backup state, it will Switch to
master fast.
Critical IP Address
Enter the critical IPv4 address here. If the critical IP is configured on one virtual
router, the virtual router cannot be activated when the critical IP address is
unreachable. One VRRP group can only track one critical IP.
Shutdown
Select to enable or disable the shutdown feature here. This feature is used to
disable a virtual router on an interface. Avoid the common mistake of shutting
down the IP address owner router before shutting down other non-owner routers.
Click the Back button to return to the previous window.
Click the Apply button to accept the changes made.
VRRPv3 Settings
This window is used to display and configure the VRRP version 3 (VRRPv3) settings.
To view the following window, click L3 Features > VRRPv3 Settings, as shown below:
