DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
336
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Please Select button, the following page will appear.
Figure 6-171 BGP Aggregate Address Settings (Please Select) Window
Select the VRF entry and click the OK button to use the selected VRF entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
BGP Network Settings
This window is used to display and configure the BGP network settings.
To view the following window, click L3 Features > BGP > BGP Network Settings, as shown below:
Figure 6-172 BGP Network Settings Window
The fields that can be configured are described below:
Parameter Description
Address Family
Select the address family to use here. Options to choose from are:
• IPv4 Unicast - Specifies to use IPv4 unicast address family here.
• IPv4 VRF - Specifies to use the VRF instance here. Enter the name of the
VRF instance in the space provided or click the Please Select button to
select a pre-configured VRF instance that will be used here. This name can
be up to 12 characters long.
• IPv4 Multicast - Specifies to use IPv4 multicast address family here.
• IPv6 Unicast - Specifies to use IPv6 unicast address family here.
Network Address
Enter the IPv4/IPv6 network address and mask that BGP will advertise here.
Route Map Name
Enter the route map name here. The configured network must be permitted by the
specified route map to be advertised. This name can be up to 16 characters long.
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
