DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
324
Click the Apply button to accept the changes made.
Click the Find button to find and display an entry based on the information entered.
MSDP Mesh Group Settings
This window is used to display and configure the MSDP mesh group settings. Before adding an MSDP peer to the
mesh group, an MSDP peer must be added first. If an MSDP peer has been added to multiple mesh groups, only the
last configuration takes effect.
To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > MSDP > MSDP Mesh
Group Settings, as shown below:
Figure 6-156 MSDP Mesh Group Settings Window
The fields that can be configured are described below:
Parameter Description
Peer Address
Enter the MSDP peer IP address here.
Mesh Name
Enter the name of the mesh group here. This string can be up to 64 characters
long.
Click the Apply button to accept the changes made.
Click the Find button to find and display an entry based on the information entered.
Click the Delete button to delete the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IPMC
IP Multicast Global Settings
This window is used to display and configure the global IP Multicast (IPMC) settings.
To view the following window, click L3 Features > IP Multicast Routing Protocol > IPMC > IP Multicast Global
Settings, as shown below:
