DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
440
Click the Back button to discard the changes made and return to the previous page.
Extended IPv6 ACL
After selecting an Extended IPv6 ACL and clicking the Add Rule button, the following page will appear.
Figure 8-14 Extended IPv6 ACL (Add Rule) Window
The fields that can be configured are described below:
Parameter Description
Sequence No.
Enter the sequence number of this ACL rule here. The range is from 1 to 65535. If
this value is not specified, the system will automatically generate an ACL rule
number for this entry.
Action
Select the action that this rule will take here. Options to choose from are Permit,
Deny, and Deny CPU.
Protocol Type
Select the protocol type option here. Options to choose from are TCP, UDP,
ICMP, Protocol ID, ESP (50), PCP (108), SCTP (132), and None.
• Value - The protocol ID can also manually be entered here. The range is
from 0 to 255.
• Mask - After selecting the Protocol ID option, manually enter the protocol
mask value here. The range is from 0x0 to 0xFF.
• Fragments - Select this option to include packet fragment filtering.
Source
Select and enter the source IPv6 information here. Options to choose from are
Any, Host, and IPv6.
• When the Any option is selected, any source traffic will be evaluated
according to the conditions of this rule.
