GVRP Port
This window is used to display and configure the GVRP port settings.
To view the following window, click L2 Features > VLAN > GVRP > GVRP Port, as shown below:
Figure 5-13 GVRP Port Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the range of ports that will be used for this configuration here.
GVRP Status
Select the enable or disable the GVRP port status. This enables the port to
dynamically become a member of a VLAN. By default, this option is disabled.
Join Time
Enter the Join Time value in centiseconds. This value must be between 10 and
10000 centiseconds. By default, this value is 20 centiseconds.
Leave Time
Enter the Leave Time value in centiseconds. This value must be between 10 and
10000 centiseconds. By default, this value is 60 centiseconds.
Leave All Time
Enter the Leave All Time value in centiseconds. This value must be between 10
and 10000 centiseconds. By default, this value is 1000 centiseconds.
Click the Apply button to accept the changes made.
GVRP Advertise VLAN
This window is used to display and configure the GVRP Advertise VLAN settings.
To view the following window, click L2 Features > VLAN > GVRP > GVRP Advertise VLAN, as shown below:
