DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
615
Configuration Backup to HTTP
This window is used to initiate a configuration file backup to a local PC using HTTP.
To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup to HTTP, as
shown below:
Figure 15-14 Configuration Backup to HTTP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
Source File
Enter the source filename and path of the configuration file located on the Switch
here. This field can be up to 64 characters long. Select the running-config option
to back up the running configuration file from the Switch. Select the startup-
config option to back up the start-up configuration file from the Switch.
Click the Backup button to initiate the configuration file backup.
Configuration Backup to TFTP
This window is used to initiate a configuration file backup to a TFTP server.
To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup to TFTP, as
shown below:
Figure 15-15 Configuration Backup to TFTP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
TFTP Server IP
Enter the TFTP server IP address here. When select the IPv4 option, enter the
IPv4 address of the TFTP server in the space provided. When the IPv6 option is
selected, enter the IPv6 address of the TFTP server in the space provided.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Source File
Enter the source filename and path of the configuration file located on the Switch
here. This field can be up to 64 characters long. Select the running-config option
to back up the running configuration file from the Switch. Select the startup-
config option to back up the start-up configuration file from the Switch.
