DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
584
Click the Back button to return to the previous window.
VPLS MAC Address Table
This window is used to clear and display VPLS MAC address information.
To view the following window, click MPLS L2VPN > VPLS MAC Address Table, as shown below:
Figure 12-9 VPLS MAC Address Table Window
The fields that can be configured are described below:
Parameter Description
VPLS Name
Enter the VPLS instance name here. This name can be up to 32 characters long.
IP Address
Enter the LSR ID that is used to identify the PE to which the peer belongs to here.
VC ID
Enter the PW VC ID here. The range is from 1 to 4294967295.
Interface
Select the Switch unit ID that will be used here.
Select the port that will be used here.
VLAN
Enter the service VLAN ID here. The range is from 1 to 4094.
MAC Address
Enter the MAC address that will be used here.
Type
Select the type of information to be specified in the search query here. Options to
choose from are None, Peer, and AC.
Click the Clear By PW button to clear the information associated with the PW specified.
Click the Clear By AC button to clear the information associated with the AC specified.
Click the Clear By MAC button to clear the information associated with the MAC address specified.
Click the Clear By VPLS button to clear the information associated with the VPLS specified.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear All button to clear all the information displayed in the table.
Click the Show All button to display all the available entries.
