DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
200
Click the Apply button to accept the changes made.
The fields that can be configured in Group Profile Table are described below:
Parameter Description
Profile Name
Enter the group profile name for the multicast VLAN feature here. This name can
be up to 32 characters long.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
Click the Delete All button to delete all the entries found in the display table.
Click the Delete button to delete the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
The fields that can be configured in Access Group Table are described below:
Parameter Description
VID
Enter the multicast VLAN ID that will be used here. The range is 1 to 4094.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
PIM Snooping
PIM Snooping Global Settings
This window is used to display and configure the global Protocol Independent Multicast (PIM) snooping settings.
To view the following window, click L2 Features > L2 Multicast Control > PIM Snooping > PIM Snooping Global
Settings, as shown below:
Figure 5-90 PIM Snooping Global Settings Window
The fields that can be configured in Global Settings are described below:
Parameter Description
Global State
Select to globally enable or disable the PIM snooping feature here.
