DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
199
Figure 5-89 Multicast VLAN Group Settings Window
The fields that can be configured in Group Profile Settings are described below:
Parameter Description
Profile Name
Enter the group profile name for the multicast VLAN feature here. This name can
be up to 32 characters long.
Action
Select the action that will be taken here. Options to choose from are Add and
Delete. Multiple ranges can be added to a multicast VLAN profile. The IP address
ranges, specified in a single profile, must be of the same address family.
Address Type
Select the address type here. Options to choose from are IPv4 and IPv6.
• IPv4 - Specifies to use IPv4 multicast addresses in the range.
• IPv6 - Specifies to use IPv6 multicast addresses in the range.
From IP Address
Enter the source IPv4/IPv6 address here.
To IP Address
Enter the destination IPv4/IPv6 address here.
Click the Apply button to accept the changes made.
The fields that can be configured in Access Group Settings are described below:
Parameter Description
VID
Enter the multicast VLAN ID that will be used here. The range is 1 to 4094.
Profile Name
Enter the group profile name for the multicast VLAN feature here. This name can
be up to 32 characters long.
Action
Select the action that will be taken here. Options to choose from are Add and
Delete. This is to add or delete the multicast group entirely.
