DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
211
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used here.
Port
Select the port number that will be used here.
Click the Clear Counter button to clear the counter information for the statistics displayed.
Click the Clear All button to clear all the counter information displayed.
LLDP Local Port Information
This window is used to display the information currently available for populating outbound LLDP advertisements.
To view the following window, click L2 Features > LLDP > LLDP Local Port Information, as shown below:
Figure 5-104 LLDP Local Port Information Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be displayed.
Port
Select the port number that will be displayed.
Click the Find button to locate a specific entry based on the information entered.
Click the Show Detail button to view detailed information of the specific port.
After clicking the Show Detail button, the following window will appear.
