DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
40
Parameter Description
From Port - To Port
Select the appropriate port range used for the configuration here.
Trap Sending
Select this option to enable or disable the sending of the SNMP notification traps
that are generated by the system.
Trap State
Select this option to enable or disable the SNMP linkChange trap.
Click the Apply button to accept the changes made.
SNMP View Table Settings
This window is used to assign views to community strings that define which MIB objects can be accessed by a remote
SNMP manager. The SNMP sub-tree OID created with this table maps SNMP users to the views created in the SNMP
User Table Settings window.
To view the following window, click Management > SNMP > SNMP View Table Settings, as shown below:
Figure 4-9 SNMP View Table Settings Window
The fields that can be configured are described below:
Parameter Description
View Name
Type an alphanumeric string of up to 32 characters. This is used to identify the
new SNMP view being created.
Subtree OID
Type the Object Identifier (OID) sub-tree for the view. The OID identifies an object
tree (MIB tree) that will be included or excluded from access by an SNMP
manager.
View Type
Select the view type here. Options to choose from are Included and Excluded.
• Included - Select to include this object in the list of objects that an SNMP
manager can access.
• Excluded - Select to exclude this object from the list of objects that an
SNMP manager can access.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specified entry.
