DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
489
Figure 9-50 ARP Inspection Log Window
The fields that can be configured are described below:
Parameter Description
Log Buffer
Enter the log buffer value used here. This value must be between 1 and 1024. By
default, this value is 32.
Click the Apply button to accept the changes made.
Click the Clear Log button to clear the log.
IP Source Guard
IP Source Guard Port Settings
This window is used to display and configure the IP source guard port settings.
To view the following window, click Security > IMPB > IPv4 > IP Source Guard > IP Source Guard Port Settings,
as shown below:
Figure 9-51 IP Source Guard Port Settings Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the appropriate port range used for the configuration here.
State
Select to enable or disable the IP source guard’s state for the specified port(s)
here.
Validation
Select the validation method used here. Options to choose from are IP and IP-
MAC. Selecting IP means that the IP address of the received packets will be
checked. Selecting IP-MAC means that the IP address and the MAC address of
the received packets will be checked.
Click the Apply button to accept the changes made.
IP Source Guard Binding
This window is used to display and configure the IP source guard binding settings.
