DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
610
Figure 15-7 Firmware Backup to TFTP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
TFTP Server IP
Enter the TFTP server IP address here. When select the IPv4 option, enter the
IPv4 address of the TFTP server in the space provided. When the IPv6 option is
selected, enter the IPv6 address of the TFTP server in the space provided.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Source File
Enter the source filename and path of the firmware file located on the Switch
here. This field can be up to 64 characters long.
Destination File
Enter the destination filename and path of the firmware file to be backed up to the
TFTP server here. This field can be up to 64 characters long.
Click the Backup button to initiate the firmware backup.
Firmware Backup to FTP
This window is used to initiate a firmware backup to an FTP server.
To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to FTP, as shown
below:
Figure 15-8 Firmware Backup to FTP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
FTP Server IP
Enter the FTP server IP address here. When select the IPv4 option, enter the
IPv4 address of the FTP server in the space provided. When the IPv6 option is
