DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
354
The fields that can be configured are described below:
Parameter Description
Address Family
Select the address family that will be used here. Options to choose from are:
• VPNv4 All - Specifies to display all BGP label information related to the
VPNv4 address family.
• VPNv4 RD - Specifies to display BGP label information related to the Route
Distinguisher (RD) in the VPNv4 address family. Enter the RD in the space
provided.
• VPNv4 VRF - Specifies to display BGP label information related to the VRF
instance in the VPNv4 address family. Enter the name of the VRF instance
here. This name can be up to 12 characters long. Alternatively, click the
Please Select button to select a pre-configured VRF instance that will be
used here.
Click the Find button to locate a specific entry based on the information selected/entered.
After clicking the Please Select button, the following page will appear.
Figure 6-195 BGP Labels Table (Please Select) Window
Select the VRF entry and click the OK button to use the selected VRF entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
BGP Neighbor
Neighbor
This window is used to display and configure the BGP neighbor settings.
To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor, as shown below:
