DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
384
Figure 6-234 ISIS Neighbors (Show Detail) Window
Click the Back button to return to the previous window.
IP Route Filter
IP Prefix List
This window is used to display and configure the IP route filter prefix list settings.
To view the following window, click L3 Features > IP Route Filter > IP Prefix List, as shown below:
Figure 6-235 IP Prefix List Window
The fields that can be configured are described below:
Parameter Description
List Name
Enter the IP prefix list name here. This name can be up to 32 characters long.
Direction
Select the direction for this rule here. Options to choose from are:
• Permit - Specifies that routes that match the rule entry are permitted.
• Deny - Specifies that routes that match the rule entry are denied.
Sequence ID
Enter the sequence ID for this rule here. The range is from 1 to 65535.
IP Network Address
Enter the starting and ending IPv4 addresses in the range used here.
