DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
28
Parameter Description
1588 protocol, this value must be represented as the logarithm to the base of 2 of
this time, measured in seconds. The range is from 1 to 2 seconds. Select the Half
Second option to set 0.5 seconds as this value.
Click the Apply button to accept the changes made.
PTP P2P Transparent Port Settings
This window is used to display and configure the peer delay request message interval on the P2P transparent clock
port(s) specified.
To view the following window, click System > PTP (Precise Time Protocol) > PTP P2P Transparent Port Settings,
as shown below:
Figure 3-23 PTP P2P Transparent Port Settings Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the range of ports that will be used for this configuration here.
P2P Transparent Pdelay
Request Interval
Enter the P2P transparent peer delay request interval value here. The range is
from 1 to 32.
Click the Apply button to accept the changes made.
PTP Clock Information
This window is used to view PTP clock information. This is used to display the active attributes of the PTP clock.
To view the following window, click System > PTP (Precise Time Protocol) > PTP Clock Information, as shown
below:
