DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
203
Figure 5-94 Multicast Filtering Window
The fields that can be configured are described below:
Parameter Description
VID List
Enter the VLAN ID list that will be used for this configuration here.
Multicast Filter Mode
Select the multicast filter mode here. Options to choose from are Forward
Unregistered, Forward All, and Filter Unregistered.
• When selecting the Forward Unregistered option, registered multicast
packets will be forwarded based on the forwarding table and all unregistered
multicast packets will be flooded based on the VLAN domain.
• When selecting the Forward All option, all multicast packets will be flooded
based on the VLAN domain.
• When selecting the Filter Unregistered option, registered packets will be
forwarded based on the forwarding table and all unregistered multicast
packets will be filtered.
Click the Apply button to accept the changes made.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
LLDP
LLDP Global Settings
This window is used to display and configure the global LLDP settings.
To view the following window, click L2 Features > LLDP > LLDP Global Settings, as shown below:
