DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
130
Parameter Description
From Port - To Port
Select the range of ports that will be used for this configuration here.
Action
Select the forbidden VLAN to port mapping action that will be taken here. Options
to choose from are All, Add, and Remove. When selecting All, all the forbidden
VLANs will be used.
Forbidden VID List
Enter the forbidden VLAN ID list here.
Click the Apply button to accept the changes made.
GVRP Statistics Table
This window is used to view GVRP statistics information.
To view the following window, click L2 Features > VLAN > GVRP > GVRP Statistics Table, as shown below:
Figure 5-16 GVRP Statistics Table Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit to be displayed here.
Port
Select the port number to display GVRP statistic information for here.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the information for the specific port.
Click the Show All button to view all GVRP statistic information.
Click the Clear All button to clear all the information in this table.
Asymmetric VLAN
This window is used to display and configure the asymmetric VLAN settings.
To view the following window, click L2 Features > VLAN > Asymmetric VLAN, as shown below:
