DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
360
Select the VRF entry and click the OK button to use the selected VRF entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Neighbor Shutdown
This window is used to shut BGP neighbors down or not.
To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor Shutdown, as shown below:
Figure 6-203 Neighbor Shutdown Window
The fields that can be configured are described below:
Parameter Description
Neighbor
Select and enter the BGP neighbor here. Options to choose from are:
• IPv4 Address - Enter the IPv4 address of the BGP neighbor here.
• IPv6 Address - Enter the IPv6 address of the BGP neighbor here.
• Peer Group - Enter the name of the peer group of the BGP neighbor here.
This name can be up to 16 characters long.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long. Click the Please Select button to select a pre-configured VRF instance that
will be used here.
Action
Select the action that will be taken here. Options to choose from are Shutdown
and No Shutdown.
Click the Apply button to accept the changes made.
After clicking the Please Select button, the following page will appear.
Figure 6-204 Neighbor Shutdown (Please Select) Window
Select the VRF entry and click the OK button to use the selected VRF entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Neighbor Map Settings
This window is used to display and configure the BGP neighbor map settings.
