DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
617
Configuration Backup to RCP
This window is used to initiate a configuration file backup to an RCP server.
To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup to RCP, as
shown below:
Figure 15-17 Configuration Backup to RCP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
RCP Server IP
Enter the RCP server IP address here.
User Name
Enter the user name used for the RCP connection here. This name can be up to
32 characters long.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Source File
Enter the source filename and path of the configuration file located on the Switch
here. This field can be up to 64 characters long. Select the running-config option
to back up the running configuration file from the Switch. Select the startup-
config option to back up the start-up configuration file from the Switch.
Destination File
Enter the destination path and location where the configuration file should be
stored on the RCP server. This field can be up to 64 characters long.
Click the Backup button to initiate the configuration file backup.
Log Backup
Log Backup to HTTP
This window is used to initiate a system log backup to a local PC using HTTP.
To view the following window, click Tools > Log Backup > Log Backup to HTTP, as shown below:
Figure 15-18 Log Backup to HTTP Window
The fields that can be configured are described below:
Parameter Description
Log Type
Select the log type that will be backed up to the local PC using HTTP.
