DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
148
Parameter Description
Type
Select the type of private VLAN that will be created here. Options to choose from
are Community, Isolated, and Primary.
Click the Apply button to accept the changes made.
The fields that can be configured for Private VLAN Association are described below:
Parameter Description
VID List
Enter the private VLAN ID list here.
Action
Select the action that will be taken for the private VLAN here. Options to choose
from are Add, Remove, and Disabled.
Secondary VID List
Enter the secondary private VLAN ID here.
Click the Apply button to accept the changes made.
The fields that can be configured for Private VLAN Host Association are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the range of ports that will be used for this configuration here. Select the
Trunk option to specify that the trunk port will be associated with the private
VLAN host association.
Primary VID
Enter the primary private VLAN ID here.
Secondary VID
Enter the secondary private VLAN ID here. When ticking the Remove
Association option, specifies that this configuration will not be enabled.
Click the Apply button to accept the changes made.
The fields that can be configured for Private VLAN Mapping are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the range of ports that will be used for this configuration here. Select the
Trunk option to specify that the trunk port will be associated with the private
VLAN map.
Primary VID
Enter the primary private VLAN ID here.
Action
Select Add to add a new entry based in the information entered.
Select Remove to remove an entry based in the information entered.
Secondary VID List
Enter the secondary private VLAN ID here. When ticking the Remove Mapping
option, this specifies that this configuration will not be enabled.
Click the Apply button to accept the changes made.
VLAN Tunnel
Dot1q Tunnel
This window is used to display and configure the 802.1Q VLAN tunnel settings.
An 802.1Q tunnel port behaves as a User Network Interface (UNI) port of a service VLAN. The trunk ports which are
tagged members of the service VLAN behave as the Network Node Interface (NNI) ports of the service VLAN.
