DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
113
Figure 4-101 Configuration File Backup/Restore Window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server IP address.
Path \ Filename
Enter the path and file name.
Click the Restore button to update the configuration from a TFTP server to the member Switch.
Click the Backup button to back up the configuration file to a TFTP server.
Upload Log File
This window is used to view and upload log files from SIM member Switches to a specified PC.
To view the following window, click Management > Virtual Stacking (SIM) > Upload Log File, as shown below:
Figure 4-102 Upload Log File Window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server IP address.
Path \ Filename
Enter the path and file name.
Click the Upload button to initiate the file transfer.
D-Link Discovery Protocol
This window is used to display and configure the D-Link Discovery Protocol (DDP) settings.
To view the following window, click Management > D-Link Discovery Protocol, as shown below:
