DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
48
Figure 4-19 RMON History Settings Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
Port
Select the port that will be used here.
Index
Enter the history group table index. The value is from 1 to 65535.
Bucket Number
Enter the number of buckets specified for the RMON collection history group of
statistics. The range is from 1 to 65535. The default value is 50.
Interval
Enter the time in seconds in each polling cycle. The range is from 1 to 3600.
Owner
Enter the owner string. The string can be up to 127 characters.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specified entry.
Click the Show Detail button to see the detail information of the specific port.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Show Detail button, the following window will appear.
Figure 4-20 RMON History Settings (Show Detail) Window
Click the Back button to return to the previous window.
RMON Alarm Settings
This window is used to display and configure alarm entries to monitor an interface.
To view the following window, click Management > RMON > RMON Alarm Settings, as shown below:
