DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
330
IPv6MC
IPv6 Multicast Global Settings
This window is used to display and configure the global IPv6 multicast settings.
To view the following window, click L3 Features > IP Multicast Routing Protocol > IPv6MC > IPv6 Multicast Global
Settings, as shown below:
Figure 6-164 IPv6 Multicast Global Settings Window
The fields that can be configured in IPv6 Multicast Routing are described below:
Parameter Description
IPv6 Multicast Routing
Global State
Select to globally enable or disable the IPv6 multicast routing feature here. When
IPv6 multicast routing is disabled, the system will stop routing multicast packets
even though the multicast routing protocol is enabled.
Click the Apply button to accept the changes made.
The fields that can be configured in IPv6 Multicast Interface Table are described below:
Parameter Description
Interface Name
Enter the VLAN interface name that will be used here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
IPv6 Static Multicast Route Settings
This window is used to display and configure the IPv6 static multicast route settings. The PIM protocol does not have
its own routing table but uses the unicast routing table to determine the reverse path forwarding interface to reach a
network. This window is used to configure static multicast route to specify the RPF address for a network.
To view the following window, click L3 Features > IP Multicast Routing Protocol > IPv6MC > IPv6 Static Multicast
Route Settings, as shown below:
