DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
207
Figure 5-98 LLDP Basic TLVs Settings Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the appropriate port range used for the configuration here.
Port Description
Select this option to enable or disable the Port Description option.
System Name
Select this option to enable or disable the System Name option.
System Description
Select this option to enable or disable the System Description option.
System Capabilities
Select this option to enable or disable the System Capabilities option.
Click the Apply button to accept the changes made.
LLDP Dot1 TLVs Settings
The LLDP Dot1 TLVs Settings page is used to enable or disable outbound LLDP advertisements for IEEE 802.1
organizationally unique port VLAN ID TLVs.
To view the following window, click L2 Features > LLDP > LLDP Dot1 TLVs Settings, as shown below:
Figure 5-99 LLDP Dot1 TLVs Settings Window
The fields that can be configured are described below:
