DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
509
The fields that can be configured are described below:
Parameter Description
Page Title
Enter a custom page title message here. This message can be up to 128
characters long.
Login Window Title
Enter a custom login window title here. This title can be up to 64 characters long.
User Name Title
Enter a custom username title here. This title can be up to 32 characters long.
Password Title
Enter a custom password title here. This title can be up to 32 characters long.
Logout Window Title
Enter a custom logout window title here. This title can be up to 64 characters long.
Notification
Enter additional information to display in the notification area here. This
information can be up to 128 characters long for each line. There a 5 lines
available for additional information.
Click the Set to Default button to replace the information with the default information.
Click the Apply button to accept the changes made.
Network Access Authentication
Guest VLAN
This window is used to display and configure the network access authentication guest VLAN settings.
To view the following window, click Security > Network Access Authentication > Guest VLAN, as shown below:
Figure 9-74 Guest VLAN Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
From Port - To Port
Select the appropriate port range used for the configuration here.
VID
Enter the VLAN ID used here. This value must be between 1 and 4094.
Click the Apply button to accept the changes made.
Click the Delete button to remove the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Network Access Authentication Global Settings
This window is used to display and configure the global Network Access Authentication settings.
