DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
42
SNMP Group Table Settings
An SNMP group created with this table maps SNMP users to the views created in the SNMP View Table Settings
window.
To view the following window, click Management > SNMP > SNMP Group Table Settings, as shown below:
Figure 4-11 SNMP Group Table Settings Window
The fields that can be configured are described below:
Parameter Description
Group Name
Enter the SNMP group name here. This name can be up to 32 characters long.
Spaces are not allowed.
Read View Name
Enter the read view name that users of the group can access.
User-based Security Model
Select the security model here. Options to choose from are SNMPv1, SNMPv2c,
and SNMPv3.
• SNMPv1 - Select to allow the group to use the SNMPv1 security model.
• SNMPv2c - Select to allow the group to use the SNMPv2c security model.
• SNMPv3 - Select to allow the group to use the SNMPv3 security model.
Write View Name
Enter the write view name that the users of the group can access.
Security Level
When selecting SNMPv3 in the User-based Security Model drop-down list, this
option is available.
• NoAuthNoPriv - Specify that there will be no authorization and no
encryption of packets sent between the Switch and a remote SNMP
manager.
• AuthNoPriv - Specify that authorization will be required, but there will be no
encryption of packets sent between the Switch and a remote SNMP
manager.
• AuthPriv - Specify that authorization will be required, and that packets sent
between the Switch and a remote SNMP manger will be encrypted.
Notify View Name
Enter the notify view name that users of the group can access. The notify view
describes the object that can be reported its status via trap packets to the group
user.
IP Address-List Name
Enter the standard IP access control list (ACL) to associate with the group.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specified entry.
