DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
518
Traffic Segmentation Settings
This window is used to display and configure the traffic segmentation settings. When the traffic segmentation
forwarding domain is specified, packets received by the port will be restricted in Layer 2 packet forwarding to
interfaces within the domain. When the forwarding domain of a port is empty, Layer 2 forwarding for packets received
by the port is not restricted.
The traffic segmentation member list can be comprised of different interface types, for example port and port-channel
in the same forwarding domain. If the interfaces specified by the command include a port-channel, all the member
ports of this port-channel will be included in the forwarding domain.
If the forwarding domain of an interface is empty, then there is no restriction on Layer 2 forwarding of packets received
by the port.
To view the following window, click Security > Traffic Segmentation Settings, as shown below:
Figure 9-83 Traffic Segmentation Settings Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the receiving Switch unit that will be used for this configuration here.
From Port - To Port
Select the receiving port range used for the configuration here.
Forward Unit
Select the forward Switch unit that will be used for this configuration here.
From Forward Port ~ To
Forward Port
Select the forward port range used for the configuration here.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove an entry based on the information entered.
Storm Control
This window is used to display and configure the storm control settings.
To view the following window, click Security > Storm Control, as shown below:
