Figure 11-5 MPLS LDP Neighbor Targeted Settings Window
The fields that can be configured are described below:
Parameter Description
Neighbor Targeted
Enter the LSR ID of the targeted peer here. The targeted peer is used to establish
the LDP session with the non-directly connected neighbor.
Targeted Hello Interval
Enter the interval to the hello message for sessions with extended peers here.
The range is from 5 to 65535 seconds. Select the Default option to use the
default value.
Targeted Hello Hold Time
Enter the hold-time of the hello messages for sessions with extended peers here.
The range is from 15 to 65535 seconds. Select the Default option to use the
default value.
Click the Apply button to accept the changes made.
Click the Delete button to remove the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
MPLS LDP Neighbor Information
This window is used to view and clear the MPLS LDP neighbor information.
To view the following window, click MPLS > MPLS LDP Neighbor Information, as shown below:
Figure 11-6 MPLS LDP Neighbor Information Window
The fields that can be configured are described below:
Parameter Description
Peer
Enter the IP address which is used as the peer LSR ID here.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear by Peer button to clear the information related to the peer entered.
