DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
147
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used in this display here.
Voice VLAN LLDP-MED Device
This window is used to view the voice VLAN LLDP-MED device table.
To view the following window, click L2 Features > VLAN > Voice VLAN > Voice VLAN LLDP-MED Device, as
shown below:
Figure 5-40 Voice VLAN LLDP-MED Device Window
Private VLAN
This window is used to display and configure the private VLAN settings.
To view the following window, click L2 Features > VLAN > Private VLAN, as shown below:
Figure 5-41 Private VLAN Window
The fields that can be configured for Private VLAN are described below:
Parameter Description
VID List
Enter the private VLAN ID list here.
State
Select to enable or disable the private VLAN state here.
