DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
235
IP Tunnel Settings
This window is used to display and configure the IP tunnel settings.
To view the following window, click L3 Features > IP Tunnel Settings, as shown below:
Figure 6-31 IP Tunnel Settings Window
The fields that can be configured are described below:
Parameter Description
Interface Tunnel ID
Enter the IP tunnel interface ID here. The range is from 0 to 9999.
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Click the Edit button to modify the specified entry.
Click the Delete button to delete the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Edit button, the following page will appear.
Figure 6-32 IP Tunnel Settings (Edit) Window
The fields that can be configured are described below:
Parameter Description
Status
Select the IP tunnel interface status here. Options to choose from are Up and
Down.
Description
Enter the description for this IP tunnel interface here. This string can be up to 64
characters long.
