DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
439
Click the Apply button to accept the changes made.
Click the Back button to discard the changes made and return to the previous page.
Standard IPv6 ACL
After selecting a Standard IPv6 ACL and clicking the Add Rule button, the following page will appear.
Figure 8-13 Standard IPv6 ACL (Add Rule) Window
The fields that can be configured are described below:
Parameter Description
Sequence No.
Enter the sequence number of this ACL rule here. The range is from 1 to 65535. If
this value is not specified, the system will automatically generate an ACL rule
number for this entry.
Action
Select the action that this rule will take here. Options to choose from are Permit,
Deny, and Deny CPU.
Source
Select and enter the source IPv6 information here. Options to choose from are
Any, Host, IPv6, and Prefix Length.
• When the Any option is selected, any source traffic will be evaluated
according to the conditions of this rule.
• When the Host option is selected, enter the source host IPv6 address here.
• When the IPv6 option is selected, the Prefix Length option will also be
available. Enter the source IPv6 address and prefix length value in the
spaces provided.
Destination
Select and enter the destination IPv6 information here. Options to choose from
are Any, Host, IPv6, and Prefix Length.
• When the Any option is selected, any destination traffic will be evaluated
according to the conditions of this rule.
• When the Host option is selected, enter the destination host IPv6 address
here.
• When the IPv6 option is selected, the Prefix Length option will also be
available. Enter the destination IPv6 address and prefix length value in the
spaces provided.
Time Range
Enter the name of the time range profile that will be used in this ACL rule here.
This name can be up to 32 characters long.
Click the Apply button to accept the changes made.
