DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
59
Figure 4-35 DHCP Server Manual Binding Window
The fields that can be configured are described below:
Parameter Description
Pool Name
Enter the DHCP server pool name here. This name can be up to 32 characters
long.
Host
Enter the DHCP host IPv4 address here.
Mask
Enter the DHCP host network subnet mask here.
Hardware Address
Enter the DHCP host MAC address here.
Client Identifier
Enter the DHCP host identifier in hexadecimal notation here. The client identifier
is formatted by the media type and the MAC address.
Click the Apply button to accept the changes made.
Click the Delete button to remove the specified entry.
DHCP Server Dynamic Binding
This window is used to view and clear the DHCP server dynamic binding entries.
To view the following window, click Management > DHCP > DHCP Server > DHCP Server Dynamic Binding, as
shown below:
Figure 4-36 DHCP Server Dynamic Binding Window
The fields that can be configured are described below:
Parameter Description
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
IP Address
Enter the binding entry IPv4 address here.
Pool Name
Enter the DHCP server pool name here. This name can be up to 32 characters
long. Select the All option to clear the binding entries for all pools.
