After clicking the Summary Prefix List button, the following page will appear.
Figure 6-223 ISIS Router Settings (Summary Prefix List) Window
The fields that can be configured are described below:
Parameter Description
Summary Address
Select the level and enter the summary prefix here.
Levels to choose from are:
• Level-1 - Specifies that only routes redistributed into level 1 are summarized
with the configured IP address and mask value.
• Level-1-2 - Specifies that summary routes are applied when redistributing
routes into level 1 and level 2 ISIS and when level 2 ISIS advertises level 1
routes as reachable in its area.
• Level-2 - Specifies that routes learned by level 1 routing are summarized
into the level 2 backbone with the configured IP address and mask value.
Redistributed routes into evel-2 ISIS will be summarized also.
Click the Apply button to accept the changes made.
Click the Back button to return to the previous window.
Click the Delete button to remove the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
ISIS Interface Settings
This window is used to display and configure the ISIS interface settings.
To view the following window, click L3 Features > ISIS > ISIS Interface Settings, as shown below:
Figure 6-224 ISIS Interface Settings Window
The fields that can be configured are described below:
