DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
195
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here. This is available
when Port is selected in the Statistics drop-down list.
From Port - To Port
Select the appropriate port range used for the configuration here. This is available
when Port is selected in the Statistics drop-down list.
Click the Clear button to clear the MLD snooping related statistics.
The fields that can be configured in MLD Snooping Statistics Table are described below:
Parameter Description
Find Type
Select the interface type. Options to choose from are VLAN, and Port.
VID
Enter a VLAN ID between 1 and 4094. This is available when VLAN is selected in
the Find Type drop-down list.
Unit
Select the Switch unit that will be used for this configuration here. This is available
when Port is selected in the Find Type drop-down list.
From Port - To Port
Select the appropriate port range used for the configuration here. This is available
when Port is selected in the Find Type drop-down list.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to view all the entries.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Multicast VLAN
Multicast VLAN Settings
This window is used to display and configure the multicast VLAN settings.
To view the following window, click L2 Features > L2 Multicast Control > Multicast VLAN > Multicast VLAN
Settings, as shown below:
