DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
550
Parameter Description
Unit
Select the Switch unit ID that will be used here.
From Port - To Port
Select the Switch port range that will be used here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
Ethernet OAM Event Log Table
This window is used to view and clear the Ethernet OAM event log table.
To view the following window, click OAM > Ethernet OAM > Ethernet OAM Event Log Table, as shown below:
Figure 10-24 Ethernet OAM Event Log Table Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit ID that will be used here.
Port
Select the Switch port that will be used here.
Action
Select the Find option to find and display the log entries associated with the
specified port.
Select the Clear option to clear the log entries associated with the specified port.
Click the Find button to find and display the log entries associated with the specified port.
Ethernet OAM Statistics Table
This window is used to view and clear the Ethernet OAM statistics table.
To view the following window, click OAM > Ethernet OAM > Ethernet OAM Statistics Table, as shown below:
