DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
292
Parameter Description
Group Address
Enter the IPv6 group multicast address here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
MLD Proxy Forwarding Table
This window is used to find and display MLD proxy forwarding information.
To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD Proxy > MLD Proxy
Forwarding Table, as shown below:
Figure 6-111 MLD Proxy Forwarding Table Window
The fields that can be configured are described below:
Parameter Description
Group Address
Enter the IPv6 group multicast address here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
DVMRP
DVMRP Interface Settings
This window is used to display and configure the Distance Vector Multicast Routing Protocol (DVMRP) interface
settings.
To view the following window, click L3 Features > IP Multicast Routing Protocol > DVMRP > DVMRP Interface
Settings, as shown below:
Figure 6-112 DVMRP Interface Settings Window
The fields that can be configured are described below:
Parameter Description
Interface Name
Enter the VLAN interface name used here.
