STP Global Settings
This window is used to display and configure the global STP settings.
To view the following window, click L2 Features > STP > STP Global Settings, as shown below:
Figure 5-50 STP Global Settings Window
The field that can be configured for STP State is described below:
Parameter Description
STP State
Select to enable or disable the global STP state here.
Click the Apply button to accept the changes made.
The fields that can be configured for STP Traps are described below:
Parameter Description
STP New Root Trap
Select to enable or disable the STP New Root Trap option here.
STP Topology Change Trap
Select to enable or disable the STP Topology Change Trap option here.
Click the Apply button to accept the changes made.
The fields that can be configured for STP Mode are described below:
Parameter Description
STP Mode
Select the STP mode used here. Options to choose from are MSTP, RSTP, and
STP.
Click the Apply button to accept the changes made.
The fields that can be configured for STP Priority are described below:
Parameter Description
Priority
Select the STP priority value here. This value is between 0 and 61440. By default,
