DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
611
Parameter Description
selected, enter the IPv6 address of the FTP server in the space provided.
TCP Port
Enter the TCP port number used for the FTP connection here. The range is from
1 to 65535.
User Name
Enter the user name used for the FTP connection here. This name can be up to
32 characters long.
Password
Enter the password used for the FTP connection here. This password can be up
to 15 characters long.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Source File
Enter the source filename and path of the firmware file located on the Switch
here. This field can be up to 64 characters long.
Destination File
Enter the destination filename and path of the firmware file to be backed up to the
FTP server here. This field can be up to 64 characters long.
Click the Backup button to initiate the firmware backup.
Firmware Backup to RCP
This window is used to initiate a firmware backup to an RCP server.
To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to RCP, as shown
below:
Figure 15-9 Firmware Backup to RCP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
RCP Server IP
Enter the RCP server IP address here.
User Name
Enter the user name used for the RCP connection here. This name can be up to
32 characters long.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Source File
Enter the source filename and path of the firmware file located on the Switch
here. This field can be up to 64 characters long.
Destination File
Enter the destination filename and path of the firmware file to be backed up to the
RCP server here. This field can be up to 64 characters long.
Click the Backup button to initiate the firmware backup.
