DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
383
Parameter Description
• IPv4 - Specifies to display the ISIS IPv4 routing table information.
• IPv6 - Specifies to display the ISIS IPv6 routing table information.
Area Tag
Enter the ISIS area tag that will be used in this display here. This can be up to 16
characters long.
Level
Select the routing level that will be used here. Options to choose from are Level-1
and Level-2.
Click the Find button to locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
ISIS Hostname
This window is used to view the router-name-to-system-ID mapping table entries for ISIS.
To view the following window, click L3 Features > ISIS > ISIS Hostname, as shown below:
Figure 6-232 ISIS Hostname Window
ISIS Neighbors
This window is used to view the ISIS neighbors’ information.
To view the following window, click L3 Features > ISIS > ISIS Neighbors, as shown below:
Figure 6-233 ISIS Neighbors Window
Click the Show Detail button to view more detailed information about the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Show Detail button, the following page will appear.
